KATHERINE
Station summaryKAT1
| IGS-type acronym : | KAT1 |
| Latitude : | -14.37600931 |
| Longitude : | 132.15326810 |
| Installed date : | 2010-03-15 |
| Decommissioned date : | |
| Country : | AUSTRALIA |
| City: | KATHERINE |
| Station status : | active (green) |
| Domes Nr.: | 59968M001 |
| Station operator: | Unknown |
| IGS-like station form : |
GPS position times seriesKAT1
(Reference epoch: )
| M | Material change or malfunction |
| E | Earthquake |
| RF | Reference Frame change |
| U | Unknown |
| NA | Not available |
| Position discontinuity | |
| Velocity discontinuity |
Data available at SONELKAT1
Quality plots on RINEX filesKAT1
 |
 |
Plots generated using software developed with the EPN team at ROB |
| Observations & tracking performance | Satellite tracking |
(this operation may take 20 to 45s)
The satellite tracking graph has been calculated for all stations for the first day of each month. If you wish to have a graph for another date, choose the 'Calculate a specific date' option.
Log bookKAT1
[IGSSTATION-7515] - 2019-01-14 (14/01/2019)
The external H-MASER timer at the CORS KAT1 was detached on 2019-01-11.
An updated station log file has been submitted to IGSCB.
Details on receiver, antenna, and timer etc. can also be found in the GNSS site manager
( https://gnss-site-manager.geodesy.ga.gov.au/siteLog/KAT1 ).
[IGSSTATION-7511] - 2019-01-09 (14/01/2019)
We have been monitoring a tracking issue with the IGS station KAT1 since 2018-12-25. At the moment we are working on getting technicians to the station to investigate further. All data streams will be suspended until the problem is resolved.
